Fluence RAZR Modular Vertical Farming LED System
Current generation. Contact our team for lead time and project scheduling.
The RAZR Modular System is a configurable vertical-farming light. Individual light bars and all mounting accessories are field replaceable, and systems run from 8 to 24 bars with power distributed evenly across them. Bars are IP67 rated for wash-down and harsh environments.
Key Features
- Broad R3a enclosed: 64 umol/s at 2.5 umol/J (RM-48-SL-BW3)
- Broad R4 enclosed: 62 umol/s at 2.7 umol/J (RM-48-SL-BW4)
- 24 to 50 W per bar
- Max 24 bars per system
- Field replaceable bars and mounts
- Mounting height above canopy > 15 cm
What's Included
- Light bars, frames, power supply, cabling and mounts to be determined per rack. Contact The Lamphouse for a system design.
Distributed in South Africa by The Lamphouse Group. Contact our team for project design, PPFD mapping and commercial pricing.
Specifications
| Light output (PPF) | 63 umol/s per light bar |
|---|---|
| Efficacy | 2.6 umol/J |
| AC input power | 215 - 620 W @ 277 V AC (system) |
| Input voltage | 120 - 277 V or 277 - 480 V AC, 50/60 Hz |
| Spectrum | PhysioSpec Broad R3a, Broad R4 |
| Beam angle | 120 deg Lambertian |
| Dimming | Source signal driver, 0/1-10 V, off, 10-100% |
| Power factor | > 0.97 (16-24 bars), > 0.92 (8-12 bars) |
| THD | < 10% (16-24 bars), < 20% (8-12 bars) |
| Lifetime | LED Q90 (L90B50) > 50 000 hrs; driver > 50 000 hrs at 40 degC |
| Maximum ambient | 40 degC [104 degF]; 35 degC [95 degF] at 120 V AC. 85% RH |
| IP rating | IP67 (light bar), IP66 (system) per IEC 60598-1 |
| Warranty | 5 Year Limited Warranty |
| Certifications | cETLus UL 8800 / CE / Wet Location / DLC |
